| Property | Value |
|---|---|
| Item | Connector |
| Max. Voltage | 30V AC/DC |
| Application | Signal |
| Standards | CSA Certified; UL E28476; UL Recognized |
| Width | 0.657 in |
| Height | 11.95 mm |
| Length | 20.3 mm |
| Material | Glass-Filled Liquid Crystal Polymer |
| Color | Black |
| For Use With | Receptacle Assembly |
| Contact Plating Thickness | 0.76 µm |
| Flammability Rating | UL 94 V-0 |
| Contact Finish | Gold Plated |
| Number of Contacts | 90 |
| Connection Material | Copper Alloy |
| Max. Temp. | 85°C |
| Hole Center to Center | 1.9 mm |
| Connector Terminates To | Printed Circuit Board |
| Hole Dia. | 0.015 in |
| Terminal Type | Through Hole - Press-Fit |
| Current Rating | 0.75 A |
| Terminal Finish | Matte Tin Plated |
| Number of Rows | 9 |
| Connector Type | Header |
| Contact Type | Pin |
| Country of Origin (subject to change) | China |
| Package Quantity | 1 |
